Complete experimental system for polarized light

Item Code: SN1092

Working and Principle :

This experiment helps students understand the concept and
mechanism of polarization. It can be used to measure
different types of polarization and the working parameters of optical elements involved. The system is a manual operation mode to help the student understand polarization principles by their operation.




  • Ideal for demo
  • Observing polarization by reflection
  • Measuring Brewster’s angle
  • Verifying Malus’s law

  • Brewster’s angle measurement of a black glass.
  • Verification of Malus’s law.
  • Function study of a half-wave plate.
  • Function study of a quarter-wave plate: circularly and elliptically polarized light.
  • Optical Rail : Duralumin, 1 m
  • Polarizer : Φ 20 mm with holder
  • λ/2 Wave Plate : Φ 10 mm, λ = 632.8 nm, quartz
  • λ/4 Wave Plate : Φ 10 mm, λ = 632.8 nm, quartz
  • Lens : f ‘= 150 mm
  • Beam Expander : f ‘= 4.5 mm
  • He-Ne Laser : >1.0 mW @632.8 nm
  • 1 Optical Rail
  • 3 General Carrier
  • 1 X-adjustable Carrier
  • 1 X-Z adjustable Carrier
  • 1 Alignment Screen
  • 2 Lens Holder
  • 1 Plate Holder
  • 1 Adaptor Piece
  • 1 Optical Goniometer
  • 3 Polarizer Holder
  • 2 Polarizer
  • 1 λ/2 Wave Plate
  • 1 λ/4 Wave Plate
  • 1 Lens
  • 1 Black Glass Sheet
  • 1 Beam Expander
  • 1 He-Ne Laser
  • 1 Laser Holder
  • 1 Optical Current Amplifier
  • Brewster’s angle
  • Malus’s law.
  • Half-wave plate
  • Quarter-wave plate
